I am writing to share the detailed specifications for wood doors to assist with our current project planning. Please see the key requirements and standards summarized below:

Dimensions and Thickness

  - Interior Doors: 1-3/8” thick
  - Exterior Doors: 1-3/4” thick
  - Commercial/Custom: 2-1/4” or thicker
  - Standard Widths: Range from 24” to 48” (typically 1/4” less than nominal to allow for clearances).
  - Standard Heights: 80”, 84”, and 96” (up to 10' for specific wood species like Cherry or Walnut).

Construction and Materials

  - Cores: Solid core options include particleboard or Structural Composite Lumber (SCL).
  - Stiles and Rails: Vertical stiles should be 5–6 inches wide with a minimum 1” laminated hardwood.
  - Veneer: A-grade wood veneers (plain or rotary sliced) over engineered cores.
  - Joints: Doweled or mortise-and-tenon construction.

Performance and Hardware

  - Fire Ratings: Available in 20-, 45-, 60-, and 90-minute ratings.
  - Hardware Prep: Machined for hinges and standard 161 (cylindrical) or 86 edge (mortise) locks.
  - Glazing: Factory-installed glass lite kits (minimum 5”–6” from door edges for fire-rated units).
  - Sustainability: Options for FSC-certified wood and low-VOC finishes.

Please let me know if you need any further clarification on these specifications or special orders.

All frames are Al powder coated with wood finishes.
